22FA4P2N103 is an PowerFlex 4M drive: 240 V AC, single phase (code b=A), 4.2 A output, 0.75 kW / 1.0 HP, frame A.
The PowerFlex 4M range runs from 0.2 to 11 kW (0.25 to 15 HP) in 120 V, 240 V and 480 V classes, and this catalog number is currently Active in the Rockwell lifecycle list.
Quick answer. 22FA4P2N103 is a Rockwell Automation PowerFlex 70 drive, 400 V AC, normal duty (), frame A, .
| 22FA011N103 | 2.2 kW | IN STOCK |
| 22FA011N113 | 2.2 kW | IN STOCK |
| 22FA1P6N103 | 0.2 kW | IN STOCK |
| 22FA1P6N113 | 0.2 kW | IN STOCK |
| 22FA2P5N103 | 0.4 kW | IN STOCK |
| 22FA2P5N113 | 0.4 kW | IN STOCK |
| 22FA4P2N103 | 0.75 kW | IN STOCK |
| 22FA4P2N113 | 0.75 kW | IN STOCK |
| 22FA8P0N103 | 1.5 kW | IN STOCK |
| 22FA8P0N113 | 1.5 kW | IN STOCK |
| 22FB012N103 | 2.2 kW | IN STOCK |
| 22FB017N103 | 3.7 kW | IN STOCK |
| 22FB025N104 | 5.5 kW | IN STOCK |
| 22FB033N104 | 7.5 kW | IN STOCK |
| 22FB1P6N103 | 0.2 kW | IN STOCK |
| 22FB2P5N103 | 0.4 kW | IN STOCK |
Catalog number |
22FA4P2N103 |
Voltage rating (b) |
A - 240 V AC, single phase (code b=A) |
Output current rating (c) |
4.2 A |
Power rating |
0.75 kW / 1.0 HP |
Frame size |
A |
Enclosure (d N) |
Panel mount IP20, NEMA/UL Type Open |
Interface module (e 1) |
Fixed keypad with 4-digit display |
EMC filter (f 0) |
no CE compliant filter fitted |
Brake (g 3) |
Not published in this position |
Rating code |
4P2 - output current in amps |
Source |
22F-TD001 p.5 Catalog Number Explanation and p.6 Product Selection |
Attribute values above are reproduced from the manufacturer's product data. For the authoritative technical record see Rockwell publications 22F-TD001 (Sept 2024) (module specifications) and 22F-UM001 (installation instructions). Certification details, with certificate and file numbers, are listed in the FAQ below.
22F is the PowerFlex 4M drive family. The next letter is the voltage class - here 240 V AC, single phase (code b=A).
The three characters after the voltage letter are the output current code, 4P2, which reads as 4.2 A. The same code means a different kW in another voltage class, so the voltage letter and the current code must be read together.
The remaining positions are N (panel mount IP20), the interface module, the EMC filter digit, the brake digit, and two reserved characters.
At 240 V AC, single phase (code b=A) the drive delivers 4.2 A continuous, 0.75 kW (1.0 HP), and 150% overload for 60 seconds or 200% for 3 seconds.
Volts per Hertz control with auto boost and slip compensation is standard; sensorless vector is not part of the 4M feature set.
Frame A is the mechanical size that decides DIN rail or panel mounting and the space needed around the drive.
Frames A and B mount on DIN rail; a virtual snap panel mount is also available.
Zero stacking is allowed at 40 C (104 F) ambient; 50 C (122 F) is permitted with minimal spacing between drives.
Integral filtering is offered on the 240 V single-phase and 480 V three-phase ratings, and external filters are available for the other ratings to meet EN 61800-3.
The full catalog number on the nameplate, because the EMC and brake digits change the hardware, not just the parameters.
Frame size against the mounting space, since frame C adds the integral brake transistor and a larger footprint.
Whether the application needs a remote keypad - the 4M supports NEMA/UL Type 4X and Type 1 handheld LCD keypads over the DSI port.
Voltage classes, current codes, kW and HP values, and frame sizes are transcribed from 22F-TD001 (September 2024), Catalog Number Explanation on page 5 and Product Selection on page 6.
Feature statements - overload, DIN rail mounting, zero stacking, integral filtering - come from the same publication, pages 3 and 4.
What is 22FA4P2N103?
PowerFlex 4M AC drive, 240 V AC, single phase (code b=A), 4.2 A, 0.75 kW / 1.0 HP, frame A.
What is the output current of 22FA4P2N103?
4.2 A at 240 V AC, single phase (code b=A).
What power rating does 22FA4P2N103 have?
0.75 kW, 1.0 HP.
What frame size is 22FA4P2N103?
Frame A.
What overload does the PowerFlex 4M allow?
150% for 60 seconds, or 200% for 3 seconds.
Related catalog numbers in the same rating code. Same A power stage, different option string - the enclosure, HIM, communication and safety positions are what change between them.
22FA011N103 (2.2 kW) · 22FA011N113 (2.2 kW) · 22FA1P6N103 (0.2 kW) · 22FA1P6N113 (0.2 kW) · 22FA2P5N103 (0.4 kW) · 22FA2P5N113 (0.4 kW) · 22FA4P2N113 (0.75 kW) · 22FA8P0N103 (1.5 kW) · 22FA8P0N113 (1.5 kW)
