22DD4P0H204 is an PowerFlex 40P drive: 480 V AC, three phase, 4.0 A output, 1.5 kW / 2.0 HP.
The 40P adds positioner and indexer functions, encoder feedback and a 24 V DC stand-alone option to the PowerFlex 40 feature set, which is why it is specified where the drive has to hold a position rather than only run a motor.
Quick answer. 22DD4P0H204 is a Rockwell Automation PowerFlex 70 drive, 400 V AC, normal duty (), frame , .
| 22DD2P3H204 | 0.75 kW / 1.0 HP | IN STOCK |
| 22DD2P3N104 | 0.75 kW / 1.0 HP | IN STOCK |
| 22DD4P0H204 | 1.5 kW / 2.0 HP | IN STOCK |
| 22DD4P0N104 | 1.5 kW / 2.0 HP | IN STOCK |
| 22DD6P0H204 | 2.2 kW / 3.0 HP | IN STOCK |
| 22DD6P0N104 | 2.2 kW / 3.0 HP | IN STOCK |
| 22DE012H204 | 7.5 kW / 10 HP | IN STOCK |
| 22DE012N104 | 7.5 kW / 10 HP | IN STOCK |
| 22DE019H204 | 11 kW / 15 HP | IN STOCK |
| 22DE019N104 | 11 kW / 15 HP | IN STOCK |
| 22DE1P7H204 | 0.75 kW / 1.0 HP | IN STOCK |
| 22DE1P7N104 | 0.75 kW / 1.0 HP | IN STOCK |
Catalog number |
22DD4P0H204 |
Voltage rating (b) |
D - 480 V AC, three phase |
Output current rating (c) |
4.0 A |
Power rating |
1.5 kW / 2.0 HP |
Enclosure (d H) |
Replacement plate drive, IP20 NEMA/UL Type Open |
Interface module (e 2) |
Fixed keypad |
Emission class (f 0) |
not filtered |
Brake (g 4) |
integral brake transistor fitted |
Rating code |
4P0 - output current in amps |
Source |
22D-TD001 Catalog Number Explanation and Drive Ratings table |
Attribute values above are reproduced from the manufacturer's product data. For the authoritative technical record see Rockwell publications 22D-TD001 (module specifications) and 22D-UM001 (installation instructions). Certification details, with certificate and file numbers, are listed in the FAQ below.
22D is the PowerFlex 40P family; position b is the voltage class, here 480 V AC, three phase.
Positions 6 to 8 are the output current code, 4P0, which reads as 4.0 A.
Position d is the enclosure (N panel, H replacement plate, F flange, C enclosed IP66), e is the interface module, f the emission class, g the brake transistor, and the last characters are reserved.
At 480 V AC, three phase the drive delivers 4.0 A continuous at 1.5 kW (2.0 HP), with 150% overload for 60 seconds and 200% for 3 seconds.
The integral brake transistor is available on all ratings, so dynamic braking needs only a resistor - no external chopper module.
A removable MOV to ground allows operation on ungrounded or resistive distribution systems, and a relay pre-charge limits inrush current.
Encoder feedback and the positioner/indexer function blocks are what separate 40P from 40; they are used for registration, indexing and simple cam replacement.
24 V DC sink or source control is set by DIP switch, so the drive can be wired to either control convention without extra hardware.
Integral RS-485 with drive serial interface protocol is standard; communication cards fit the same option slot as the PowerFlex 40.
The enclosure letter (d) because the plate, flange and enclosed versions are different mechanical builds of the same drive.
The emission digit (f) - f=1 carries the filter, f=0 does not.
Whether the brake transistor digit (g) is 4, since the integral transistor changes the braking wiring.
Voltage classes, current codes, kW and HP values, enclosure letters and option digits are transcribed from 22D-TD001: Catalog Number Explanation and the Drive Ratings table for 380-480 V and 460-600 V input.
Feature statements - overload, integral brake transistor, removable MOV, relay pre-charge, encoder feedback and positioner - come from the same publication's features section.
What is 22DD4P0H204?
PowerFlex 40P AC drive, 480 V AC, three phase, 4.0 A, 1.5 kW / 2.0 HP.
What is the output current of 22DD4P0H204?
4.0 A at 480 V AC, three phase.
What power rating does %s have?
1.5 kW, 2.0 HP.
What enclosure does 22DD4P0H204 use?
Replacement plate drive, IP20 NEMA/UL Type Open.
Does 22DD4P0H204 have an integral brake transistor?
integral brake transistor fitted.
Related catalog numbers in the same rating code. Same A power stage, different option string - the enclosure, HIM, communication and safety positions are what change between them.
22DD2P3H204 (0.75 kW / 1.0 HP) · 22DD2P3N104 (0.75 kW / 1.0 HP) · 22DD4P0N104 (1.5 kW / 2.0 HP) · 22DD6P0H204 (2.2 kW / 3.0 HP) · 22DD6P0N104 (2.2 kW / 3.0 HP) · 22DE012H204 (7.5 kW / 10 HP) · 22DE012N104 (7.5 kW / 10 HP) · 22DE019H204 (11 kW / 15 HP) · 22DE019N104 (11 kW / 15 HP)
