22BB8P0N104 is an PowerFlex 40 drive: 240 V AC, three phase, 8.0 A output, 1.5 kW / 2.0 HP, frame A.
PowerFlex 40 runs 0.4 to 11 kW (0.5 to 15 HP) across 120 V, 240 V, 480 V and 600 V classes, with sensorless vector control, integral RS-485 and a PID process loop as standard.
Quick answer. 22BB8P0N104 is a Rockwell Automation PowerFlex 70 drive, 400 V AC, normal duty (), frame A, .
| 22BB8P0C104 | 1.5 kW / 2.0 HP | IN STOCK |
| 22BB5P0N104 | 0.75 kW / 1.0 HP | IN STOCK |
| 22BB8P0F104 | 1.5 kW / 2.0 HP | IN STOCK |
| 22BB8P0H204 | 1.5 kW / 2.0 HP | IN STOCK |
| 22BB8P0N104 | 1.5 kW / 2.0 HP | IN STOCK |
| 22BD010C104 | 4.0 kW / 5.0 HP | IN STOCK |
| 22BD010F104 | 4.0 kW / 5.0 HP | IN STOCK |
| 22BD010H204 | 4.0 kW / 5.0 HP | IN STOCK |
| 22BD010N104 | 4.0 kW / 5.0 HP | IN STOCK |
| 22BD012F104 | 5.5 kW / 7.5 HP | IN STOCK |
| 22BD012H204 | 5.5 kW / 7.5 HP | IN STOCK |
| 22BD012N104 | 5.5 kW / 7.5 HP | IN STOCK |
| 22BD017F104 | 7.5 kW / 10 HP | IN STOCK |
| 22BD017H204 | 7.5 kW / 10 HP | IN STOCK |
Catalog number |
22BB8P0N104 |
Voltage rating (b) |
B - 240 V AC, three phase |
Output current rating (c) |
8.0 A |
Power rating |
1.5 kW / 2.0 HP |
Frame size |
A |
Enclosure (d N) |
Panel mount, IP20 NEMA/UL Type Open |
Interface module (e 1) |
Fixed keypad |
Emission class (f 0) |
not filtered |
Brake IGBT (g 4) |
with brake IGBT |
Rating code |
8P0 - output current in amps |
Source |
22-TD001 p.8 Catalog Number Explanation and p.9 Product Selection |
Attribute values above are reproduced from the manufacturer's product data. For the authoritative technical record see Rockwell publications 22-TD001 (Sept 2024) (module specifications) and 22B-UM001 (installation instructions). Certification details, with certificate and file numbers, are listed in the FAQ below.
22B is the PowerFlex 40 family. Position b is the voltage class - here 240 V AC, three phase.
Positions 6 to 8 are the output current code, 8P0, which reads as 8.0 A. The same code means a different kW in another voltage class, so b and c must be read together.
Position d is the enclosure, e is the interface module, f the emission class, g the brake IGBT, and the last two characters are reserved for custom firmware.
At 240 V AC, three phase the drive delivers 8.0 A continuous at 1.5 kW (2.0 HP), with 150% overload for 60 seconds and 200% for 3 seconds.
Control is sensorless vector or volts per hertz, selectable; the process PID loop, timer, counter, basic logic and StepLogic functions are built in, so simple sequences do not need a separate controller.
Frame A sets the mounting and the option kits: the IP30 Type 1 conversion kit is 22-JBAC for frame C and 22-JBAB for frame B.
d=N is the panel mount plate drive with IP20 NEMA/UL Type Open; d=H is the same drive supplied as a replacement plate for an existing installation; d=F is the flange mount for heatsink-through-panel mounting.
d=C is the IP66 NEMA/UL Type 4X/12 enclosed version and is offered on frame B only.
An IP30 NEMA/UL Type 1 kit converts an open drive for cabinet-free mounting where that rating is required.
The full 14-character catalog number, because the enclosure letter (d) and the brake digit (g) change the hardware.
Whether the drive carries the EMC filter digit f=1; unfiltered drives need an external filter to meet EN 61800-3.
Frame size and depth, since the flange and IP66 versions add hardware that a plate drive does not have.
Voltage classes, current codes, kW and HP values, frame sizes, enclosure and option codes are transcribed from 22-TD001 (September 2024): Catalog Number Explanation on page 8 and Product Selection on page 9.
Feature statements - overload, sensorless vector, PID, StepLogic, integral RS-485, IP66 frame B limit - come from the feature comparison on page 7 and the option tables on page 10.
What is 22BB8P0N104?
PowerFlex 40 AC drive, 240 V AC, three phase, 8.0 A, 1.5 kW / 2.0 HP, frame A.
What is the output current of 22BB8P0N104?
8.0 A at 240 V AC, three phase.
What power rating does 22BB8P0N104 have?
1.5 kW, 2.0 HP.
What enclosure does 22BB8P0N104 use?
Panel mount, IP20 NEMA/UL Type Open.
Does 22BB8P0N104 have an EMC filter?
Not filtered.
Related catalog numbers in the same rating code. Same A power stage, different option string - the enclosure, HIM, communication and safety positions are what change between them.
22BB8P0C104 (1.5 kW / 2.0 HP) · 22BB5P0N104 (0.75 kW / 1.0 HP) · 22BB8P0F104 (1.5 kW / 2.0 HP) · 22BB8P0H204 (1.5 kW / 2.0 HP) · 22BD010C104 (4.0 kW / 5.0 HP) · 22BD010F104 (4.0 kW / 5.0 HP) · 22BD010H204 (4.0 kW / 5.0 HP) · 22BD010N104 (4.0 kW / 5.0 HP) · 22BD012F104 (5.5 kW / 7.5 HP)
