22BB024H204 is an PowerFlex 40 drive: 240 V AC, three phase, 24 A output, 5.5 kW / 7.5 HP, frame B.
PowerFlex 40 runs 0.4 to 11 kW (0.5 to 15 HP) across 120 V, 240 V, 480 V and 600 V classes, with sensorless vector control, integral RS-485 and a PID process loop as standard.
Quick answer. 22BB024H204 is a Rockwell Automation PowerFlex 70 drive, 400 V AC, normal duty (), frame B, .
| 22BB012C104 | 2.2 kW / 3.0 HP | IN STOCK |
| 22BB012F104 | 2.2 kW / 3.0 HP | IN STOCK |
| 22BB012H204 | 2.2 kW / 3.0 HP | IN STOCK |
| 22BB012N104 | 2.2 kW / 3.0 HP | IN STOCK |
| 22BB017C104 | 3.7 kW / 5.0 HP | IN STOCK |
| 22BB017F104 | 3.7 kW / 5.0 HP | IN STOCK |
| 22BB017H204 | 3.7 kW / 5.0 HP | IN STOCK |
| 22BB017N104 | 3.7 kW / 5.0 HP | IN STOCK |
| 22BB024F104 | 5.5 kW / 7.5 HP | IN STOCK |
| 22BB024H204 | 5.5 kW / 7.5 HP | IN STOCK |
| 22BB024N104 | 5.5 kW / 7.5 HP | IN STOCK |
| 22BB033F104 | 7.5 kW / 10 HP | IN STOCK |
| 22BB033H204 | 7.5 kW / 10 HP | IN STOCK |
| 22BB033N104 | 7.5 kW / 10 HP | IN STOCK |
| 22BB2P3C104 | 0.4 kW / 0.5 HP | IN STOCK |
| 22BB2P3F104 | 0.4 kW / 0.5 HP | IN STOCK |
| 22BB2P3H204 | 0.4 kW / 0.5 HP | IN STOCK |
| 22BB2P3N104 | 0.4 kW / 0.5 HP | IN STOCK |
| 22BB5P0C104 | 0.75 kW / 1.0 HP | IN STOCK |
Catalog number |
22BB024H204 |
Voltage rating (b) |
B - 240 V AC, three phase |
Output current rating (c) |
24 A |
Power rating |
5.5 kW / 7.5 HP |
Frame size |
B |
Enclosure (d H) |
Replacement plate drive, IP20 NEMA/UL Type Open |
Interface module (e 2) |
Fixed keypad |
Emission class (f 0) |
not filtered |
Brake IGBT (g 4) |
with brake IGBT |
Rating code |
024 - output current in amps |
Source |
22-TD001 p.8 Catalog Number Explanation and p.9 Product Selection |
Attribute values above are reproduced from the manufacturer's product data. For the authoritative technical record see Rockwell publications 22-TD001 (Sept 2024) (module specifications) and 22B-UM001 (installation instructions). Certification details, with certificate and file numbers, are listed in the FAQ below.
22B is the PowerFlex 40 family. Position b is the voltage class - here 240 V AC, three phase.
Positions 6 to 8 are the output current code, 024, which reads as 24 A. The same code means a different kW in another voltage class, so b and c must be read together.
Position d is the enclosure, e is the interface module, f the emission class, g the brake IGBT, and the last two characters are reserved for custom firmware.
At 240 V AC, three phase the drive delivers 24 A continuous at 5.5 kW (7.5 HP), with 150% overload for 60 seconds and 200% for 3 seconds.
Control is sensorless vector or volts per hertz, selectable; the process PID loop, timer, counter, basic logic and StepLogic functions are built in, so simple sequences do not need a separate controller.
Frame B sets the mounting and the option kits: the IP30 Type 1 conversion kit is 22-JBAC for frame C and 22-JBAB for frame B.
d=N is the panel mount plate drive with IP20 NEMA/UL Type Open; d=H is the same drive supplied as a replacement plate for an existing installation; d=F is the flange mount for heatsink-through-panel mounting.
d=C is the IP66 NEMA/UL Type 4X/12 enclosed version and is offered on frame B only.
An IP30 NEMA/UL Type 1 kit converts an open drive for cabinet-free mounting where that rating is required.
The full 14-character catalog number, because the enclosure letter (d) and the brake digit (g) change the hardware.
Whether the drive carries the EMC filter digit f=1; unfiltered drives need an external filter to meet EN 61800-3.
Frame size and depth, since the flange and IP66 versions add hardware that a plate drive does not have.
Voltage classes, current codes, kW and HP values, frame sizes, enclosure and option codes are transcribed from 22-TD001 (September 2024): Catalog Number Explanation on page 8 and Product Selection on page 9.
Feature statements - overload, sensorless vector, PID, StepLogic, integral RS-485, IP66 frame B limit - come from the feature comparison on page 7 and the option tables on page 10.
What is 22BB024H204?
PowerFlex 40 AC drive, 240 V AC, three phase, 24 A, 5.5 kW / 7.5 HP, frame B.
What is the output current of 22BB024H204?
24 A at 240 V AC, three phase.
What power rating does 22BB024H204 have?
5.5 kW, 7.5 HP.
What enclosure does 22BB024H204 use?
Replacement plate drive, IP20 NEMA/UL Type Open.
Does 22BB024H204 have an EMC filter?
Not filtered.
Related catalog numbers in the same rating code. Same A power stage, different option string - the enclosure, HIM, communication and safety positions are what change between them.
22BA012F104 (2.2 kW / 3.0 HP) · 22BA012H204 (2.2 kW / 3.0 HP) · 22BA012N104 (2.2 kW / 3.0 HP) · 22BA012N114 (2.2 kW / 3.0 HP) · 22BA2P3F104 (0.4 kW / 0.5 HP) · 22BA2P3H204 (0.4 kW / 0.5 HP) · 22BA2P3N104 (0.4 kW / 0.5 HP) · 22BA2P3N114 (0.4 kW / 0.5 HP) · 22BA5P0C104 (0.75 kW / 1.0 HP) · 22BA5P0F104 (0.75 kW / 1.0 HP)
