22AB1P5H204 is an PowerFlex 4 drive: 240 V AC, three phase, 1.5 A output, 0.2 kW / 0.25 HP, frame A.
PowerFlex 4 is the entry member of the PowerFlex family: volts per hertz control, a fixed keypad with speed pot, and the same 4-digit display and parameter set as the larger 4M and 40 drives.
Quick answer. 22AB1P5H204 is a Rockwell Automation PowerFlex 70 drive, 400 V AC, normal duty (), frame A, .
| 22AA8P0H204 | 1.5 kW / 2.0 HP | IN STOCK |
| 22AA8P0N104 | 1.5 kW / 2.0 HP | IN STOCK |
| 22AA8P0N114 | 1.5 kW / 2.0 HP | IN STOCK |
| 22AA9P6N103 | 2.2 kW / 3.0 HP | IN STOCK |
| 22AA9P6N113 | 2.2 kW / 3.0 HP | IN STOCK |
| 22AB012H204 | 2.2 kW / 3.0 HP | IN STOCK |
| 22AB012N104 | 2.2 kW / 3.0 HP | IN STOCK |
| 22AB017H204 | 3.7 kW / 5.0 HP | IN STOCK |
| 22AB017N104 | 3.7 kW / 5.0 HP | IN STOCK |
| 22AB1P5H204 | 0.2 kW / 0.25 HP | IN STOCK |
| 22AB1P5N104 | 0.2 kW / 0.25 HP | IN STOCK |
| 22AB2P3H204 | 0.4 kW / 0.5 HP | IN STOCK |
| 22AB2P3N104 | 0.4 kW / 0.5 HP | IN STOCK |
| 22AB4P5H204 | 0.75 kW / 1.0 HP | IN STOCK |
| 22AB4P5N104 | 0.75 kW / 1.0 HP | IN STOCK |
| 22AB8P0H204 | 1.5 kW / 2.0 HP | IN STOCK |
| 22AD8P7N104 | 3.7 kW / 5.0 HP | IN STOCK |
| 22AV1P5H204 | 0.2 kW / 0.25 HP | IN STOCK |
| 22AV1P5N104 | 0.2 kW / 0.25 HP | IN STOCK |
Catalog number |
22AB1P5H204 |
Voltage rating (b) |
B - 240 V AC, three phase |
Output current rating (c) |
1.5 A |
Power rating |
0.2 kW / 0.25 HP |
Frame size |
A |
Enclosure (d H) |
Replacement plate drive, IP20 NEMA/UL Type Open |
Interface module (e 2) |
Fixed keypad with speed pot |
Emission class (f 0) |
not filtered |
Brake IGBT (g 4) |
with brake IGBT |
Rating code |
1P5 - output current in amps |
Source |
22-TD001 p.9 Product Selection table |
Attribute values above are reproduced from the manufacturer's product data. For the authoritative technical record see Rockwell publications 22-TD001 (Sept 2024) (module specifications) and 22A-UM001 (installation instructions). Certification details, with certificate and file numbers, are listed in the FAQ below.
22A is the PowerFlex 4 family; position b is the voltage class, here 240 V AC, three phase.
Positions 6 to 8 are the output current code, 1P5, which reads as 1.5 A - the same code means a different kW on another voltage class.
Position d is the enclosure letter, e the interface module, f the emission class, g the brake IGBT; the final two characters are reserved.
At 240 V AC, three phase the drive delivers 1.5 A continuous at 0.2 kW (0.25 HP), with 150% overload for 60 seconds and 200% for 3 seconds.
Control is volts per hertz with auto boost and slip compensation. Sensorless vector and the process PID loop are not part of the PowerFlex 4 feature set - that is what the 4M and 40 add.
Frame A sets the DIN rail and panel mounting options and the space needed around the drive.
DIN rail mounting is standard on the PowerFlex 4 frames, with an optional panel mount kit.
A removable MOV to ground allows the drive to run on ungrounded distribution systems, and a relay pre-charge limits inrush current.
An integral keypad with speed potentiometer is fitted as standard, so the drive can be commissioned without a PC.
The full catalog number, because the enclosure letter (d) and brake digit (g) change the hardware.
Whether the EMC filter digit is 1; unfiltered drives need an external filter to meet EN 61800-3.
The frame size against the panel space, since frame B is wider and needs clearance for heat sinks.
Voltage classes, current codes, kW and HP values, frame sizes, enclosure and option codes are transcribed from 22-TD001 (September 2024), Catalog Number Explanation on page 8 and Product Selection on page 9.
Feature statements - V/Hz control, DIN rail mounting, removable MOV, integral keypad with speed pot - come from the feature comparison on page 7.
What is 22AB1P5H204?
PowerFlex 4 AC drive, 240 V AC, three phase, 1.5 A, 0.2 kW / 0.25 HP, frame A.
What is the output current of 22AB1P5H204?
1.5 A at 240 V AC, three phase.
What power rating does 22AB1P5H204 have?
0.2 kW, 0.25 HP.
What frame size is 22AB1P5H204?
Frame A.
What control type does the PowerFlex 4 use?
Volts per hertz with auto boost and slip compensation.
Related catalog numbers in the same rating code. Same A power stage, different option string - the enclosure, HIM, communication and safety positions are what change between them.
22AA1P4N103 (0.2 kW / 0.25 HP) · 22AA1P4N113 (0.2 kW / 0.25 HP) · 22AA1P5F104 (0.2 kW / 0.25 HP) · 22AA1P5H204 (0.2 kW / 0.25 HP) · 22AA1P5N104 (0.2 kW / 0.25 HP) · 22AA1P5N114 (0.2 kW / 0.25 HP) · 22AA2P1N103 (0.4 kW / 0.5 HP) · 22AA2P1N113 (0.4 kW / 0.5 HP) · 22AA2P3H204 (0.4 kW / 0.5 HP) · 22AA2P3N104 (0.4 kW / 0.5 HP)
