Allen Bradley PowerFlex 22A-B017H204 / 22AB017H204

China Allen Bradley PowerFlex 22A-B017H204 / 22AB017H204 supplier
Allen Bradley PowerFlex 22A-B017H204 / 22AB017H204 supplier Allen Bradley PowerFlex 22A-B017H204 / 22AB017H204 supplier Allen Bradley PowerFlex 22A-B017H204 / 22AB017H204 supplier Allen Bradley PowerFlex 22A-B017H204 / 22AB017H204 supplier Allen Bradley PowerFlex 22A-B017H204 / 22AB017H204 supplier Allen Bradley PowerFlex 22A-B017H204 / 22AB017H204 supplier Allen Bradley PowerFlex 22A-B017H204 / 22AB017H204 supplier Allen Bradley PowerFlex 22A-B017H204 / 22AB017H204 supplier Allen Bradley PowerFlex 22A-B017H204 / 22AB017H204 supplier Allen Bradley PowerFlex 22A-B017H204 / 22AB017H204 supplier Allen Bradley PowerFlex 22A-B017H204 / 22AB017H204 supplier Allen Bradley PowerFlex 22A-B017H204 / 22AB017H204 supplier Allen Bradley PowerFlex 22A-B017H204 / 22AB017H204 supplier Allen Bradley PowerFlex 22A-B017H204 / 22AB017H204 supplier Allen Bradley PowerFlex 22A-B017H204 / 22AB017H204 supplier

Large Image :  Allen Bradley PowerFlex 22A-B017H204 / 22AB017H204

Product Details:

Place of Origin: Made in CHINA
Brand Name: PLC Module
Certification: All goods we supply are 100% original factory sealed with 1 year warranty!
Model Number: Allen Bradley PowerFlex 22A-B017H204 / 22AB017H204

Payment & Shipping Terms:

Minimum Order Quantity: 1 /PCS
Price: $373.00 (USD/PCS)
Packaging Details: 100% original new
Delivery Time: IN STOCK; 4-6 weeks for ordering
Payment Terms: T/T, Western Union and Paypal.
Supply Ability: 5 PCS
Detailed Product Description

22AB017H204 technical data PDF download 22AB017H204 PowerFlex 4 3.7 kW 5.0 HP AC drive

Category: PLCs, Power Supplies & I/Os
Manufacturer: Rockwell
Group: PowerFlex 70 drives

22AB017H204 is an PowerFlex 4 drive: 240 V AC, three phase, 17.5 A output, 3.7 kW / 5.0 HP, frame B.

PowerFlex 4 is the entry member of the PowerFlex family: volts per hertz control, a fixed keypad with speed pot, and the same 4-digit display and parameter set as the larger 4M and 40 drives.

Quick answer. 22AB017H204 is a Rockwell Automation PowerFlex 70 drive, 400 V AC, normal duty (), frame B, .

  • Normal duty output current:
  • Motor rating:
  • Frame: B
  • Enclosure:
  • Communication slot:
  • Control and I/O:
22AA6P8N103 1.5 kW / 2.0 HP IN STOCK
22AA6P8N113 1.5 kW / 2.0 HP IN STOCK
22AA8P0H204 1.5 kW / 2.0 HP IN STOCK
22AA8P0N104 1.5 kW / 2.0 HP IN STOCK
22AA8P0N114 1.5 kW / 2.0 HP IN STOCK
22AA9P6N103 2.2 kW / 3.0 HP IN STOCK
22AA9P6N113 2.2 kW / 3.0 HP IN STOCK
22AB012H204 2.2 kW / 3.0 HP IN STOCK
22AB012N104 2.2 kW / 3.0 HP IN STOCK
22AB017H204 3.7 kW / 5.0 HP IN STOCK
22AB017N104 3.7 kW / 5.0 HP IN STOCK
22AB1P5H204 0.2 kW / 0.25 HP IN STOCK
22AB1P5N104 0.2 kW / 0.25 HP IN STOCK
22AB2P3H204 0.4 kW / 0.5 HP IN STOCK
22AB2P3N104 0.4 kW / 0.5 HP IN STOCK
22AB4P5H204 0.75 kW / 1.0 HP IN STOCK
22AB4P5N104 0.75 kW / 1.0 HP IN STOCK
22AB8P0H204 1.5 kW / 2.0 HP IN STOCK
22AD8P7N104 3.7 kW / 5.0 HP IN STOCK

Product Specifications 22AB017H204 (PDF)
 Catalog number
 22AB017H204
 Voltage rating (b)
 B - 240 V AC, three phase
 Output current rating (c)
 17.5 A
 Power rating
 3.7 kW / 5.0 HP
 Frame size
 B
 Enclosure (d H)
 Replacement plate drive, IP20 NEMA/UL Type Open
 Interface module (e 2)
 Fixed keypad with speed pot
 Emission class (f 0)
 not filtered
 Brake IGBT (g 4)
 with brake IGBT
 Rating code
 017 - output current in amps
 Source
 22-TD001 p.9 Product Selection table

Attribute values above are reproduced from the manufacturer's product data. For the authoritative technical record see Rockwell publications 22-TD001 (Sept 2024) (module specifications) and 22A-UM001 (installation instructions). Certification details, with certificate and file numbers, are listed in the FAQ below.

How to read this catalog number

22A is the PowerFlex 4 family; position b is the voltage class, here 240 V AC, three phase.

Positions 6 to 8 are the output current code, 017, which reads as 17.5 A - the same code means a different kW on another voltage class.

Position d is the enclosure letter, e the interface module, f the emission class, g the brake IGBT; the final two characters are reserved.

What the rating means on this voltage class

At 240 V AC, three phase the drive delivers 17.5 A continuous at 3.7 kW (5.0 HP), with 150% overload for 60 seconds and 200% for 3 seconds.

Control is volts per hertz with auto boost and slip compensation. Sensorless vector and the process PID loop are not part of the PowerFlex 4 feature set - that is what the 4M and 40 add.

Frame B sets the DIN rail and panel mounting options and the space needed around the drive.

Installation and environment

DIN rail mounting is standard on the PowerFlex 4 frames, with an optional panel mount kit.

A removable MOV to ground allows the drive to run on ungrounded distribution systems, and a relay pre-charge limits inrush current.

An integral keypad with speed potentiometer is fitted as standard, so the drive can be commissioned without a PC.

What to verify before buying

The full catalog number, because the enclosure letter (d) and brake digit (g) change the hardware.

Whether the EMC filter digit is 1; unfiltered drives need an external filter to meet EN 61800-3.

The frame size against the panel space, since frame B is wider and needs clearance for heat sinks.

Documented source

Voltage classes, current codes, kW and HP values, frame sizes, enclosure and option codes are transcribed from 22-TD001 (September 2024), Catalog Number Explanation on page 8 and Product Selection on page 9.

Feature statements - V/Hz control, DIN rail mounting, removable MOV, integral keypad with speed pot - come from the feature comparison on page 7.

FAQ — 22AB017H204

What is 22AB017H204?

PowerFlex 4 AC drive, 240 V AC, three phase, 17.5 A, 3.7 kW / 5.0 HP, frame B.

What is the output current of 22AB017H204?

17.5 A at 240 V AC, three phase.

What power rating does 22AB017H204 have?

3.7 kW, 5.0 HP.

What frame size is 22AB017H204?

Frame B.

What control type does the PowerFlex 4 use?

Volts per hertz with auto boost and slip compensation.

Related catalog numbers in the same rating code. Same A power stage, different option string - the enclosure, HIM, communication and safety positions are what change between them.

22AA1P4N103 (0.2 kW / 0.25 HP) · 22AA1P4N113 (0.2 kW / 0.25 HP) · 22AA1P5F104 (0.2 kW / 0.25 HP) · 22AA1P5H204 (0.2 kW / 0.25 HP) · 22AA1P5N104 (0.2 kW / 0.25 HP) · 22AA1P5N114 (0.2 kW / 0.25 HP) · 22AA2P1N103 (0.4 kW / 0.5 HP) · 22AA2P1N113 (0.4 kW / 0.5 HP) · 22AA2P3H204 (0.4 kW / 0.5 HP) · 22AA2P3N104 (0.4 kW / 0.5 HP)


Data sources. Decoded from Rockwell 22-TD001 p.8-9 Catalog Number Explanation and Product Selection Any attribute a publication does not print is marked Not published rather than taken from a distributor page. Catalog number, packaging and stock status are the stock record of this listing.
